60w 120vac⇴24vdc X-Series Class 2 Compact Dimmable LED Driver

The X-Series electronic power supplies for LEDs is designed to deliver power to today’s
LED light sources.

The advanced circuitry of the X-Series enables it to operate smoothly with line power dimmer switches as well as architectural type dimming controls, without using an interface. All X-Series power supplies are not limited by a minimum load requirement like previous conventional transformers.

X-Series supplies are available in a wide variety of combinations of common input and output voltages.

You are sure to find a power supply to meet the requirements of your most demanding applications.

Advantages

• Miniature casing
• Designed for architectural lighting control systems
• Compatible with regular line dimmers
• Smooth dimming with LED light sources
• No minimum load requirement
• Easily controllable
• Noiseless operation under dimming conditions
• No zero cross-over blinking
• Suitable for LED loads
• Works well with MR16 replacement LEDs
• Approved to FKSZ2/8
• Approved to QQIJ2
• Approved to CSA C22.2 No. 107.1-01

Specifications

• Available in 120VAC, 230VAC, 277VAC input
• Available in 12 VAC, 12VDC, 24VAC, 24VDC output
• Maximum load of 60W or 75W
• THD < 13%
• Power factor > 0.97 (without dimmer with LED light strip or halogens)
• Class A insulation isolation transformer
• Maximum casing temperature of 90 °C
• Maximum amb. oper. temp. of 40 °C
• Suitable for damp and dry locations
